Item

Technical Specification

Image device

1/2.8” Color CMOS

TV System

25fps / 30fps

Effective Pixels

1920(H) x1080(V)

Sensing Area

5.568mm(H) x 3.132mm(V)

Scanning System

Progress

Sync. System

Internal

Resolution

FHD 1080P

Horizontal Sync. Frequency

1H Period=35.56us/29.63us

Vertical Sync. Frequency

25Hz/30Hz

Minimum Illumination

0.1 Lux(day),0 Lux(with IR)

Microphone

Optional

Video Output

1.0Vp-p,75 Ohm

Gamma Consumption

0.45

AGC

Auto

Signal to noise ratio

Better than 52dB

White balance

Auto

Electronic Shutter

1/25(1/30)~1/50,000 Seconds

Backlight Compensation

Auto

Power Supply

DC 12V/DC 10-32V(Optional)

Operating Temperature

-20℃ ~ +70℃,RH 95% MAX.

Storage Temperature

-30℃ ~ +80℃,RH 95% MAX.

Lens Angle

240°,200°,150°, 130°,110°,100°70°,50°,35°(depending on models)
